Brand：Atlas Copco
Minimum：1
Unit：Set
Pack：Neutral packing or customized
Technical parameter
| Air compressor model number | XAS57E | XAS77E | XAS486E | XAMS396E | XAMS466E | |
| Compressed series | 1 | 1 | ||||
| Rated working pressure | bar | 7 | 8.6 | |||
| Displacement | m3/min | 3 | 4.2 | 28.5 | 23.4 | 28.2 |
| Motor model | Y2-160L-2 | Y2-180L-2 | YLF315L1-4 | YLF315L1-4 | YLF315L1-4 | |
| The motor power | Kw | 18.5 | 26 | 160 | 160 | 160 |
| The service factor | 1.15 | 1 | 1 | 1.15 | ||
| Motor speed | rpm | 2940 | 1480 | |||
| The power supply | V/Ph/Hz | 380/3/50 | ||||
| Oil content of gas | mg/m3 | <=5 | ||||
| Exhaust valve dimensions | nch | 2xG3/4 | G21/2+G11/4+G3/4 | |||
| Dimensions (trailer type) | mm | 2685x1310x1205 | 4684x1685x1999 | |||
| Dimensions (box type) | mm | 1520x956x1130 | 3500X1685X1900 | |||
| Weight (trailer/box) | Kg | 550/510 | 3600/3350 | |||
| Air compressor model number | XAHS376E | XAVS306E | XAVS336E | XRHS930E | XRHS1150E | XRVS960E |
| Compressed series | 1 | 1 | 1 | 2 | 2 | 2 |
| Rated working pressure bar | 12 | 14 | 14 | 20 | 20 | 25 |
| Displacement m3/min | 22.7 | 18.6 | 20 | 26.7 | 32 | 27 |
| Motor model | YLF315L1-4 | YLF315L1-4 | YLF315L1-4 | YE2-355M1-4 | YE2-355M2-4 | YE2-355M2-4 |
| Motor power Kw | 160 | 160 | 160 | 230 | 275 | 275 |
| The service factor | 1.15 | 1.15 | 1.2 | 1.15 | 1.15 | 1.15 |
| Motor speed rpm | 1480 | 1490 | ||||
| Power V/Ph/Hz | 380/3/50 | 380/3/50 | ||||
| Gas oil content mg/m3 | <=5 | <=5 | ||||
| Exhaust valve size inch | G21/2+G11/4+G3/4 | G2+G3/4 | ||||
| Size (trailer type) mm | 4684x1685x1999 | 5546x2100x2681 | ||||
| Size (box type) mm | 3500X1685X1900 | 4716x2100x2541 | ||||
| Weight (trailer/box)Kg | 3600/3350 | 5614/5114 | ||||
