Atlas Copco offers a complete spectrum of advanced oil-free compressor technologies—spanning screw, tooth, centrifugal, reciprocating, and scroll designs—engineered to meet your precise operational needs. Recognizing that oil-free compressed air is critical for countless manufacturing processes, we guarantee unwavering air purity. Our robust system safeguards are meticulously implemented to prevent any risk of oil contamination, ensuring consistent, high-quality output for your production lines.
Product Features
1. Air Inlet Filter
Breathe easy with our high-efficiency paper cartridge air inlet filter, engineered to capture dust and particles as small as 1 µm. It ensures only clean, pure air enters the system, protecting internal components and delivering consistent, reliable performance.
2. Automatic Regulation
Save energy and cut costs effortlessly. Our intelligent automatic regulation system stops the compressor the moment your required working pressure is reached, eliminating wasted power during idle periods and maximizing operational efficiency.
3. High Efficiency Scroll Element
Built to last, our air-cooled scroll compressor element is a testament to durability and reliability. Its precision design not only guarantees long-term performance but also delivers exceptional energy efficiency, keeping your operational costs low.
4. IP55 Class F/IE3 Motor
Powering your operations with uncompromised efficiency, our totally enclosed air-cooled IP55 Class F motor meets the strict IE3 and Nema Premium efficiency standards. It’s designed to withstand harsh environments while minimizing energy consumption, reducing your carbon footprint and utility bills.
5. Refrigerant Dryer
Protect your compressed air network from rust and corrosion with our compact, optimized integrated refrigerant dryer. It ensures a steady supply of dry air, extending the lifespan of your equipment and maintaining air quality for critical applications.
6. Silent Canopy
No more noisy disruptions. Our sound-insulated canopy reduces noise levels to an impressively low 53 dB(A), allowing you to install the compressor directly near your workspace. Enjoy a quieter environment without sacrificing performance.
7. Integrated Receiver
Experience true plug-and-play convenience with our integrated receiver options. Choose from 30l, 270l, or 500l tank-mounted configurations to minimize installation costs and get your system up and running in no time.
8. Elektronikon® (SF+)
Take full control of your compressor with the advanced Elektronikon® (SF+) system. It offers real-time monitoring with warning indications, automated maintenance scheduling, and online visualization of running conditions, ensuring optimal performance and minimizing downtime.
9. Innovative Design
Our new compact vertical setup redefines usability. It provides easy access for maintenance, enhances cooling efficiency to keep working temperatures low, and includes built-in vibration damping for smoother, quieter operation.
10. Cooler & Piping
Technical specifications
| TYPE | Max. working pressure | Capacity FAD* | Installed motor power | Noise level** | Weight | |||||
| bar(e) | psig | l/s | m3/min | cfm | kW | hp | dB(A) | kg | lbs | |
| SF 1-6/2+-6+(50/60 Hz) | ||||||||||
| SF 1 | 8 | 116 | 2.9 | 0.17 | 6.1 | 1.5 | 2 | 53 | 120 | 265 |
| 10 | 145 | 1.9 | 0.11 | 4 | 1.5 | 2 | 53 | 120 | 265 | |
| SF 2 / SF 2+ | 8 | 116 | 4.2 | 0.25 | 8.9 | 2.2 | 3 | 55 | 125 | 276 |
| 10 | 145 | 3.4 | 0.2 | 7.2 | 2.2 | 3 | 55 | 125 | 276 | |
| SF 4 / SF 4+ | 8 | 116 | 6.7 | 0.4 | 14.2 | 3.7 | 5 | 57 | 133 | 293 |
| 10 | 145 | 5.9 | 0.35 | 12.5 | 3.7 | 5 | 57 | 133 | 293 | |
| SF 6 / SF 6+ | 8 | 116 | 9.8 | 0.59 | 20.8 | 5.5 | 7.5 | 59 | 157 | 346 |
| 10 | 145 | 7.6 | 0.46 | 16.1 | 5.5 | 7.5 | 59 | 157 | 346 | |
| SF 8+-22+(50/60 Hz) | ||||||||||
| SF 8+ | 8 | 116 | 13.4 | 0.8 | 28.4 | 8 | 10 | 63 | 372 | 820 |
| 10 | 145 | 11.4 | 0.68 | 24.2 | 8 | 10 | 63 | 372 | 820 | |
| SF 11+ | 8 | 116 | 20.3 | 1.22 | 43 | 11 | 15 | 63 | 418 | 921 |
| 10 | 145 | 15 | 0.9 | 31.8 | 11 | 15 | 63 | 418 | 921 | |
| SF 15+ | 8 | 116 | 27.1 | 1.63 | 57.4 | 15 | 20 | 63 | 580 | 1278 |
| 10 | 145 | 23 | 1.38 | 48.7 | 15 | 20 | 63 | 580 | 1278 | |
| SF 17+ | 8 | 116 | 31.1 | 1.87 | 65.9 | 17 | 22 | 64 | 573 | 1263 |
| 10 | 145 | 23.7 | 1.42 | 50.2 | 17 | 22 | 64 | 573 | 1263 | |
| SF 22+ | 8 | 116 | 40.8 | 2.45 | 86.5 | 22 | 30 | 65 | 687 | 1514 |
| 10 | 145 | 30 | 1.8 | 63.6 | 22 | 30 | 65 | 687 | 1514 | |
| SFD 11+-22+ (50/60 Hz) | ||||||||||
| SFD 11+ | 8 | 116 | 9.8 | 0.59 | 20.8 | 11 | 15 | 63 | 450 | 992 |
| 10 | 145 | 7.6 | 0.46 | 16.1 | 11 | 15 | 63 | 450 | 992 | |
| SFD 15+ | 8 | 116 | 13.4 | 0.8 | 28.4 | 15 | 20 | 64 | 625 | 1378 |
| 10 | 145 | 11.4 | 0.68 | 24.2 | 15 | 20 | 64 | 625 | 1378 | |
| SFD 22+ | 8 | 116 | 20.3 | 1.22 | 43 | 22 | 30 | 65 | 725 | 1598 |
| 10 | 145 | 15 | 0.9 | 31.8 | 22 | 30 | 65 | 725 | 1598 | |
Performance & Acoustic Measurement Standards
Free Air Delivery (FAD) is determined in strict accordance with ISO 1217, Edition 4 (2009), Annex C. Mean sound pressure levels are measured per ISO 2151, reported with an uncertainty margin of ±3 dB(A).
Unit Weights
Refer to the accompanying chart for detailed weight specifications of both pack-mounted and floor-mounted configurations.
